Description
L1600 SUBMERSIBLE BILGE PUMP 24V DC
The best choice when you are looking for a high performance, heavy duty bilge pump that is designed to meet & exceed the tough demands of commercial & recreational duty.
This pump has a liquid cooled, 12-pole motor with double ball bearings for extended service life. The L1600 has a lip seal.
Universal base plate and a choice of 1-1/2″ or 2″ ports makes for a simple installation.
All pumps include a removable check valve.
Specifications:
Model: L1600
Shaft: SS2343
Wire Size: 1.5mm²
Max Diameter: 108mm
Max Height: 149mm
Weight: 1.3kg
Specifications
| Flow Rate | 100LPM (1600 GPH) at 13.6V |
| Flow Rate 1 Metre Head | 98 LPM (1550 GPH) at 13.6V |
| Automatic Bilge Pumps | No |
| Hose Size | 38mm / 1-1/2″, 51mm / 2″ |
| Inlet Outlet Port Size | 1-1/2″ & 2″ |
| Brand | Johnson |
| Model | L1600 |
| Voltage | 24V DC |
| Amps | 3.5A |
| Fuse | 6A |
Manufacturer Part Number: 33-1600-02
