Description
| Specifications | |
|---|---|
| Amperage | 40A |
| Maximum Voltage | 120V AC 32V DC |
| Circuit Breaker Type | Thermal trip, manual push-button reset only |
| Terminal Stud Torque | 30 in-lb (3.39 Nm) |
| Interrupt Capacity* | 3000A @ 120V AC 5000A @ 32V DC |
| Minimum Operating Temperature | -54° C |
| Maximum Operating Temperature | 74° C |
| Mounting Screw Thread | #8-32 |
| Terminal Stud | #10-32 Stainless Steel |
| Weight | 0.16lb (0.07 kg) |
*The fault current that a device, normally a fuse or circuit breaker is capable of breaking without damage.
