Description
| Specifications | |
|---|---|
| Action* | (ON)-OFF-ON |
| Pole / Throw | DPDT |
| Actuator Colour | Black – Contura III |
| Common Applications | dual wipers |
| Maximum Amperage** | 20A @ 12V 15A @ 24V |
| Amperage Operating Current | 18mA (LED) |
| Minimum Operating Temperature | -40° C |
| Maximum Operating Temperature | 85° C |
| Actuator Position to Light LED | ON |
| Embedded LEDs | 1 |
| Lighting | LED rated 100,000 hours half-life |
| Seals | Internal and external gasket panel seal |
| Weight | 0.09Lb (0.04 Kg) |
| Weight | 0.09lb (0.04 kg) |
*() = Momentary ON
**Maximum amperage ratings are dependent on the use of appropriately sized fused and wire for a given application
